    5mm To 15mm Pitch Chain Link Conveyor Belt Ladder Conveyor Belt For Bread

    Ask Lasest Price
    Brand Name : COMESH
    Model Number : AIL250212
    Price : negotiation
    Payment Terms : T/T
    Supply Ability : 100m per month
    Delivery Time : 5-8days
    • Product Details
    • Company Profile

    5mm To 15mm Pitch Chain Link Conveyor Belt Ladder Conveyor Belt For Bread

    Chain Link Stainless Steel Wire Mesh Ladder Conveyor Belt For Bread


    mesh Conveyor Belts Description


    Ladder Belt: it is also called chocolate conveyor belt, which is made by assembling bent stainless steel wires. This innovative design lasts significantly longer than other flex-style belts:

    1. hinges rather than flexing
    2. lasts 10X longer than traditional flex-style belts
    3. eliminates edge curling, snags and tangling


    mesh Conveyor Belts specification


    Namestainless steel conveyor belt
    MaterialSS304 wire ,SS 316 wire
    Wire diameter(2)1.5mm,1.8mm,2mm,2.5mm
    Span (space)(3)60mm,65mm,70mm,75mm
    Spiral pitch(1)10mm,13mm,15mm,20mm
    Roll wide20cm,48cm,50cm
    We can make it as customer's customized

    Specifications of Conveyor Belts
    ItemWire diameterPitchOpen areaEdge type
    (mm)(mm)(%)
    FFCB-010.94.2477Single/ double
    FFCB-020.95.6482Single/ double
    FFCB-0315.579Single/ double
    FFCB-0415.679.5Single/ double
    FFCB-051.274.367Single
    FFCB-061.275.573Single/ double
    FFCB-071.27676Single/ double
    FFCB-081.276.3577Single/ double
    FFCB-091.277.2680Single/ double/ C-shape
    FFCB-101.46.476Single/ C-shape
    FFCB-111.67.2675Single/ double/ C-shape
    FFCB-121.831281Single
    FFCB-131.8312.782Single/ C-shape
    FFCB-142.089.675Single/ C-shape
    FFCB-152.3512.778Single/ C-shape
    FFCB-162.3520.3285Single
    FFCB-172.812.772Single/ C-shape
    Note: Custom specification is available if you can't find the suitable size.

    mesh Conveyor Belts advantage


    1.Has resistance to acid,alkali,and low and high tempertures.
    2.Has good conveying function,break resistance as well as antioxidation
    3.With professional desigh and compact form,it is very easy to install and steadily run without deflrction.


    Wire Conveyor Belts application


    Widely used in many automatic glass work ; petro chemistry fiber ; food industry ; glass fiber ; electric furnace; kiln furnace ; machinery ; power metallurgy ; purging; reflux welding ; metal heat treatment and stoving furance etc
